Renegade™ Compact Stainless Steel Hopper Spreaders

  • Capacity: 0.35 & 0.7 cu yd
  • Materials: Salt, Sand, Fine Materials, Pre-Wet* & Liquid Brine*
  • Delivery System: Chain or Auger
  • #: 12140-1, 12145-1, 86403, 86405

Make The Choice

Bring the performance of bulk material spreading to smaller areas with the compact Renegade line. The S070A and S070C are suited for half-ton and light duty pickup trucks and the S035A and S035C are purpose-built for mid-duty UTVs and compact trucks.

Compatible with UTVs & Trucks

Unique Features

Standard Features

Product Specs

Metric
Models8640312145-18640512140-1
Smart Model NumberS035C (Chain)S035A (Auger)S070C (Chain)S070A (Auger)
Smart Model NumberS035C (Chain)S035A (Auger)S070C (Chain)S070A (Auger)
Vehicle CompatibilityUTVsUTVs½, ¾ or 1-Ton Pickup Truck½, ¾ or 1-Ton Pickup Truck
Vehicle CompatibilityUTVsUTVs½, ¾ or 1-Ton Pickup Truck½, ¾ or 1-Ton Pickup Truck
Material CompatibilityBagged Salt, Bulk Salt, Bulk Sand, & 50/50 Mix & Fine MaterialsBagged Salt, Bulk Salt & Fine MaterialsBulk Sand, Bulk Salt, 50/50 Mix, Fine Materials, Pre-Wet* & Liquid Brine*Bulk Salt, Fine Materials, Pre-Wet* & Liquid Brine*
Vehicle CompatibilityBagged Salt, Bulk Salt, Bulk Sand, & 50/50 Mix & Fine MaterialsBagged Salt, Bulk Salt & Fine MaterialsBulk Sand, Bulk Salt, 50/50 Mix, Fine Materials, Pre-Wet* & Liquid Brine*Bulk Salt, Fine Materials, Pre-Wet* & Liquid Brine*
Capacity (Volume)0.35 cu yd0.35 cu yd0.7 cu yd0.7 cu yd
Capacity (Volume)0.27 cu m0.27 cu m0.54 cu m0.54 cu m
Capacity (Weight)750 lb750 lb1,500 lb1,500 lb
Capacity (Weight)340.2 kg340.2 kg680.39 kg680.39 kg
Spreading WidthSalt: Up to 36'
Sand: Up to 24'
Salt: Up to 36'Salt: Up to 36'
Sand: Up to 24'
Salt: Up to 36'
Spreading WidthSalt: Up to 10.97 m
Sand: 7.32 m
Salt: Up to 10.97 mSalt: Up to 10.97 m
Sand: 7.32 m
Salt: Up to 10.97 m
Approx. Weight**
(Empty)
235 lb192 lb420 lb337 lb
Approx. Weight**
(Empty)
106.59 kg87.1 kg190.51 kg152.9 kg
Overall Dimensions (LxWxH)57" x 38" x 46"52.75” x 38” x 45.5”81” x 43” x 46”81" x 42.75" x 45"
Overall Dimensions (LxWxH)1.45 x 0.97 m x 1.17 m
1.34 m x 0.97 m x 1.16 m2.06 m x 1.09 m x 1.17 m2.06 m x 1.09 m x 1.14 m
Hopper Dimensions (LxWxH)30” x 38” x 26”30" x 38" x 25.75"54” x 43” x 28”54.5" x 42.75" x 27.25"
Hopper Dimensions (LxWxH)0.76 m x 0.97 m x 0.66 m0.76 m x 0.97 m x 0.65 m1.37 m x 1.09 m x 0.71 m1.38 m x 1.09 m x 1.14 m
Body Side Length30"30"54"54"
Body Side Length0.76 m0.76 m1.37 m1.37 m
Min. Bed Length30"30"44"44"
Min. Bed Length0.76 m0.76 m1.1 m1.1 m
Material Delivery Dimensions15.5" Wide4" Diameter15.5" Wide4" Diameter
Material Delivery Dimensions15.5" Wide4" Diameter39.37 cm Wide10.2 cm Diameter
Hopper Construction16 Gauge Stainless Steel16 Gauge Stainless Steel16 Gauge Stainless Steel16 Gauge Stainless Steel
Hopper Construction16 Gauge Stainless Steel16 Gauge Stainless Steel16 Gauge Stainless Steel16 Gauge Stainless Steel
Spinner Size12" Diameter12" Diameter12" Diameter12" Diameter
Spinner Size30.5 cm Diameter30.5 cm Diameter30.5 cm Diameter30.5 cm Diameter
* C = Pintle Chain Conveyor / A = HELIXX Shaftless Auger
* Accessory required for pre-wet and liquid brine (not compatible for 0.35 cu yd)
** Material weight equates to approximately 2,160 lb/cu yd or 80 lb/cu ft for 1 bag of rock salt.

Material Compatibility

Material Compatibility

CAUTION: Viscous or tacky substances or those containing solid particles are not recommended as these will clog pumps and nozzles. WARNING: DO NOT USE any products containing petroleum or petroleum by-products of any kind. These destroy seals and will void warranty.
