Renegade™ Stainless Steel Hopper Spreader

NEW!
  • Capacity: 1.5 - 5.0 cu yd
  • Materials: Salt & Sand
  • Spread Pattern: Broadcast

Spread Your Way

You need ice control equipment that makes those late nights and early mornings productive and safe. Our all-new Renegade stainless steel hopper spreaders are ready to deliver results … even in the most challenging winter conditions.

Spread your way by choosing the best material delivery system for your operation … either the HELIXX™ shaftless auger for precise rock salt application or a new pintle chain conveyor that’s perfect for dense, heavy de-icing materials.

Unique Features

Standard Spreader Features

Product Specs

Metric
ModelsS150C* / S150A*S220C* / S220A*S300C* / S300A*S400C* / S400A*S500C* / S500A*
Vehicle Compatibility3/4- & 1-Ton Pickup Trucks3/4- & 1-Ton Pickup TrucksDump Body or Flatbed Trucks (Over 15,000 lb GVWR)Dump Body or Flatbed Trucks (Over 15,000 lb GVWR)Dump Body or Flatbed Trucks (Over 15,000 lb GVWR)
Vehicle Compatibility3/4- & 1-Ton Pickup Trucks3/4- & 1-Ton Pickup TrucksDump Body or Flatbed Trucks (Over 15,000 lb GVWR)Dump Body or Flatbed Trucks (Over 15,000 lb GVWR)Dump Body or Flatbed Trucks (Over 15,000 lb GVWR)
Material CompatibilityChain: Sand & Salt/Sand Mix
Auger: Bulk Rock Salt
Chain: Sand & Salt/Sand Mix
Auger: Bulk Rock Salt
Chain: Sand & Salt/Sand Mix
Auger: Bulk Rock Salt
Chain: Sand & Salt/Sand Mix
Auger: Bulk Rock Salt
Chain: Sand & Salt/Sand Mix
Auger: Bulk Rock Salt
Vehicle CompatibilityChain: Sand & Salt/Sand Mix
Auger: Bulk Rock Salt
Chain: Sand & Salt/Sand Mix
Auger: Bulk Rock Salt
Chain: Sand & Salt/Sand Mix
Auger: Bulk Rock Salt
Chain: Sand & Salt/Sand Mix
Auger: Bulk Rock Salt
Chain: Sand & Salt/Sand Mix
Auger: Bulk Rock Salt
Capacity (Volume)1.5 cu yd2.2 cu yd3.0 cu yd4.0 cu yd5.0 cu yd
Capacity (Volume)1.15 cu m1.68 cu m2.29 cu m3.06 cu m3.82 cu m
Capacity (Weight)3,240 lb4,752 lb6,480 lb8,640 lb10,800 lb
Capacity (Weight)1,470 kg2,155 kg2,939 kg3,919 kg4,899 kg
Spreading WidthSalt: Up to 36'
Sand: Up to 24'
Salt: Up to 36'
Sand: Up to 24'
Salt: Up to 36'
Sand: Up to 24'
Salt: Up to 36'
Sand: Up to 24'
Salt: Up to 36'
Sand: Up to 24'
Spreading WidthSalt: Up to 10.97 m
Sand: 7.32 m
Salt: Up to 10.97 m
Sand: 7.32 m
Salt: Up to 10.97 m
Sand: 7.32 m
Salt: Up to 10.97 m
Sand: 7.32 m
Salt: Up to 10.97 m
Sand: 7.32 m
Approx. Weight**
(Empty)
Chain: 530 lb
Auger: 500 lb
Chain: 580 lb
Auger: 550 lb
Chain: 750 lb
Auger: 700 lb
Chain: 820 lb
Auger: 770 lb
Chain: 910 lb
Auger: 850 lb
Approx. Weight**
(Empty)
Chain: 240 kg
Auger: 227 kg
Chain: 263 kg
Auger: 249 kg
Chain: 340 kg
Auger: 318 kg
Chain: 372 kg
Auger: 349 kg
Chain: 413 kg
Auger: 386 kg
Overall Dimensions (LxWxH)Chain: 107" x 50" x 51.75"
Auger: 111.5" x 50" x 50.5"
Chain: 119.25" x 50" x 55.50"
Auger: 123" x 50" x 54.25"
Chain: 120.5" x 70" x 72.75"
Auger: 123" x 70" x 71.50"
Chain: 126.25" x 70" x 75.50"
Auger: 129" x 70" x 74.25"
Chain: 126.25" x 70" x 82.25"
Auger: 129" x 70" x 81"
Overall Dimensions (LxWxH)Chain: 2.72 m x 1.27 m x 131.45 cm
Auger: 2.83 m x 1.27 m x 128.27 cm
Chain: 3.03 m x 1.27 m x 104.97 cm
Auger: 3.12 m x 1.27 m x 137.8 cm
Chain: 3.06 m x 1.78 m x 184.79 cm
Auger: 3.12 m x 1.78 m x 181.61 cm
Chain: 3.21 m x 1.78 m x 191.77 cm
Auger: 3.27 m x 1.78 m x 188.6 cm
Chain: 3.21 m x 1.78 m x 208.92 cm
Auger: 3.27 m x 1.78 m x 205.74 cm
Hopper Dimensions (LxWxH)Chain: 84.5" x 50" x 32"
Auger: 84.5" x 50" x 32"
Chain: 96.5" x 50" x 35.75"
Auger: 96.5" x 50" x 35.75"
Chain: 96.5" x 70" x 41"
Auger: 96.5" x 70" x 41"
Chain: 108.5" x 70" x 43.75"
Auger: 108.5" x 70" x 43.75"
Chain: 108.5" x 70" x 50.5"
Auger: 108.5" x 70" x 50.5"
Hopper Dimensions (LxWxH)Chain: 2.15 m x 1.27 m x 0.81 m
Auger: 2.15 m x 1.27 m x 0.81 m
Chain: 2.45 m x 1.27 m x 0.91 m
Auger: 2.45 m x 1.27 m x 0.91 m
Chain: 2.45 m x 1.78 m x 1.04 m
Auger: 2.45 m x 1.78 m x 1.04 m
Chain: 2.76 m x 1.78 m x 1.11 m
Auger: 2.76 m x 1.78 m x 1.11 m
Chain: 2.76 m x 1.78 m x 1.28 m
Auger: 2.76 m x 1.78 m x 1.28 m
Body Side Length7'8’8'9'9'
Body Side Length2.13 m2.43 m2.43 m2.74 m2.74 m
Rec. Bed Length76"90"90"96"96"
Rec. Bed Length1.93 m2.29 m2.29 m2.44 m2.44 m
Material Delivery DimensionsChain: 16" Wide
Auger: 6" Diameter
Chain: 16" Wide
Auger: 6" Diameter
Chain: 16" Wide
Auger: 6" Diameter
Chain: 16" Wide
Auger: 6" Diameter
Chain: 16" Wide
Auger: 6" Diameter
Material Delivery DimensionsChain: 40.64 cm Wide
Auger: 15.24 cm Diameter
Chain: 40.64 cm Wide
Auger: 15.24 cm Diameter
Chain: 40.64 cm Wide
Auger: 15.24 cm Diameter
Chain: 40.64 cm Wide
Auger: 15.24 cm Diameter
Chain: 40.64 cm Wide
Auger: 15.24 cm Diameter
Hopper ConstructionRiveted Stainless SteelRiveted Stainless SteelRiveted Stainless SteelRiveted Stainless SteelRiveted Stainless Steel
Hopper ConstructionRiveted Stainless SteelRiveted Stainless SteelRiveted Stainless SteelRiveted Stainless SteelRiveted Stainless Steel
Spinner Size16" Diameter16" Diameter16" Diameter16" Diameter16" Diameter
Spinner Size40.64 cm Diameter40.64 cm Diameter40.64 cm Diameter40.64 cm Diameter40.64 cm Diameter
* C = Pintle Chain Conveyor / A = HELIXX Shaftless Auger
** Material weight equates to approximately 2,160 lb/cu yd or 80 lb/cu ft for 1 bag of rock salt.
